| NO | Code | Size |
|---|---|---|
| 1 | MDML025P | 20*1/2 |
| 2 | MDML026P | 20*3/4 |
| 3 | MDML027P | 20*1 |
| 4 | MDML028P | 25*1/2 |
| 5 | MDML029P | 25*3/4 |
| 6 | MDML030P | 25*1 |
| 7 | MDML031P | 32*1/2 |
| 8 | MDML032P | 32*3/4 |
| 9 | MDML033P | 32*1 |
| 10 | MDML034P | 32*11/4 |
| 11 | MDML035P | 40*1 |
| 12 | MDML036P | 40*11/4 |
| 13 | MDML037P | 40*11/2 |
| 14 | MDML038P | 50*11/4 |
| 15 | MDML039P | 50*11/2 |
| 16 | MDML040P | 50*2 |
| 17 | MDML041P | 63*11/4 |
| 18 | MDML042P | 63*11/2 |
| 19 | MDML043P | 63*2 |
| 20 | MDML044P | 63*21/2 |
| 21 | MDML045P | 75*2 |
| 22 | MDML046P | 75*21/2 |
| 23 | MDML047P | 75*3 |
| 24 | MDML048P | 90*21/2 |
| 25 | MDML049P | 90*3 |
| 26 | MDML050P | 90*4 |
| 27 | MDML051P | 110*3 |
| 28 | MDML052P | 110*4 |
| Color | Blue,Black,Green,Yellow or Customized |
| Service | OEM & ODM |
| HS Code | 3917400000 |
| Connection | quick connect |
| Application | Water Supply & Irrigation |
| Standard | DIN4726/16892 |
| Pressure | 16bar/1.6Mpa |
| Specification | 20mm -110mm |
| Origin | China |
PP compression fittings are widely used in water supply systems, agricultural irrigation networks, landscaping irrigation, and industrial fluid transmission. They offer a reliable and robust connection solution for polyethylene (PE) pipes.
Our PP compression fittings are designed to operate at a maximum working pressure of up to 16 bar (1.6 MPa) at room temperature, meeting standards such as DIN4726/16892.
No, one of the greatest benefits of PP compression fittings is their simple quick-connect mechanism. For smaller sizes (up to 32mm), they can easily be tightened by hand. For larger sizes, a standard strap wrench or pipe wrench is sufficient.
Yes, polypropylene (PP) material is highly resistant to UV radiation, chemical exposure, and corrosion. This makes the fittings exceptionally durable for outdoor agricultural use and underground pipeline systems.
We offer standard sizes ranging from 20mm up to 110mm, catering to various residential, agricultural, and industrial pipeline requirements. Custom sizes can also be negotiated.
